EQ5116TPBL6D11 Model technical parameters | |||
Name: | EQ5116TPBL6D11 | Exterior size(mm): | 6770,7220×2400,2550×2680 |
Chassis: | EQ1116GL6DJ1 | Container size(mm): | ×× |
Total weight :(kg) | 11200 | Approach angle/ Departure angle(° ) | 17/24 |
Payload:(kg) | 6305,6175,5955,5855,6370,6240,6020,5920 | Front suspension/rear suspension(mm): | 1200/1970,1200/2070 |
Kerb Mass:(kg) | 4700,4830,5050,5150(Kg) | Max Speed(km/h): | 88 |
Chassis parameters | |||
Chassis: | EQ1116GL6DJ1 | Axle weight: | 4000/7200 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3600,3950 | Fronttread(mm): | 1740,1770 |
Max people in cab: | 3,2 | Rear tread(mm): | 1640,1590 |
Number of tires: | 6 | Number of spring axle: | 8/10+7,9/10+8 |
Tire Type: | 8.25R16 18PR,8.25R20 16PR,8.25R16LT 18PR | ||
introduction: | 1.侧防护与后防护材质:Q235,侧防护与车架采用螺栓连接后防护焊接连接;后部防护断面尺寸(高×宽)为120×60(mm),离地高度480mm,460mm,440mm,400mm;2:ABS的型号及生产厂家:J ABS/焦作博瑞克控制技术有限公司;3.该车型可选装ETC车载装置;4.随底盘选装驾驶室不带遮阳罩;选装一体式后视镜;5.发动机D30TCIF1,YCY30165-60对应的油耗值均为19.7L/100km.,6:总长/前悬/轴距/后悬对应关系:6770/1200/3600/1970,7220/1200/3950/2070;7:选装液压爬梯和非液压爬梯样式,选装平板形式/爬梯形式/不带后爬梯,选装尾部标志板;8.选装驾驶室新风格装饰件,车门拉花,油箱涂装. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
YCY30165-60 D30TCIF1 |
广西玉柴机器股份有限公司 昆明云内动力股份有限公司 |
2970 2977 |
121/164 125/170 |
other parameters |
Introduction: |
